Paper cushion machine F40



   Paper cushion machine F40
Paper cushion instead of harmful packing material

The DTM Paper cushion machine F40 is the ideal solution for your economic packing. From 1-3 paper rolls there is a cushion of air-chambers built, which is then cut to the right length by our digital control or by foot switch. One paper roll is equivalent to 4 sacks of plastic chips.

Operation modes
  • Manually via foot switch
  • Step
  • Automatic (continually)
  • Automatic (Machine waits for the paper to be removed)
The paper cushion
  • Middle seam with high stability
  • Seam only 36 mm
  • Many air-chambers
  • Big cushion-effect
  • Efficiency and cheap
Paper
  • DTM 100% recyclable paper
  • 70 g/m², roll diameter approx. 220 mm
  • Width: 730 mm, approx. 200 meters
  • Weight: ca. 20 kg/roll
Advantages
  • Clean and economic
  • Biodegradable
  • Lease storage place
  • Dust-free and Antistatic
  • No problems of disposal



  Technical data
  Type: Paper cushion machine F40
  Speed: up to 3 meters per second
  Control: SPS
  Height: variable from 1250 mm to 1900 mm
  Width: 925 mm
  Depth: 1500 mm
  Weight: 154 kg
  Energy: 230 V / 50 Hz
